- Processor: Intel Xeon E5-2609 v3 1.9GHz, 15M Cache, 85W or Intel Xeon E5-2630 v3 2.4GHz, 20M Cache, 85W
- Memory: 16GB( 2 x 8GB) RDIMM, 2133MT/s, Single Rank, x8 Data Width
- Hard Drive: 1TB 7.2K RPM NL SAS 3.5-inch Hot Plug
- Storage Controller: Raid PERC H330 Integrated Mini -type, No Cache ( RAID 0,1,5,10,50 )
- File Access Protocols: CIFS, NFS, FTP, SMB3.0, SMB Direct (RDMA)
- Broadcom 5720 QP 1Gb Network Daughter Card
- Internal Drive Support: 12 x 3.5" hot-plug drive bays
- Power: Dual, Hot-plug, Redundant Power Supply (1+1), 750W
- OS: Microsoft Windows Storage Server 2012 R2 Standard Edition Microsoft Windows Storage
- Form Factor: 2U rack mount system
- Warranty: 3 Year ProSupport and NBD On-site Service
Management
Dell OpenManage™ featuring Dell Management Console, iDRAC8 Enterprise, Native Java RDP plug-in or Windows Server Management interface
Data Protection Features
DFS-R (Replication), VSS (Snapshots)
Data Management Features
Data deduplication with compression, FCI (File Classification Infrastructure), FSRM (File Server Resource Manager)
Product Configurations | Model NX3230 |
Storage | Up to 12 x 3.5” drives |
Max Internal Capacity | 96TB raw capacity using 8TB HDDs |
Types of Data | File and Block (Microsoft iSCSI target) |
Drive Capacities | SATA (7.2K): 2TB, 4TB
|
External Expansion | PowerVault, EqualLogic and Compellent controllers and |
Technical Highlights | Model NX3230 |
Form Factor | 2U rack mount system |
Processor | Intel Xeon E5-2609 v3 1.9GHz, 15M Cache, 85W or Intel Xeon E5-2630 v3 2.4GHz, 20M Cache, 85W |
File Access Protocols | CIFS, NFS, FTP, SMB3.0, SMB Direct (RDMA) |
Block Access Protocols | Microsoft iSCSI target |
OS supported | Microsoft Windows Storage Server 2012 R2 Standard Edition |
Standard RAID Options | OS HDDs (on rear 2.5” HDDs) are always RAID1. Data HDDs can be configured from factory in RAID5 or RAID6 (minimum 4 HDDs).The internal PERC can support additional customer configurable RAID options. |
Custom RAID Options | As supported by internal PERC H730 (0,1,5,6,10,50,60) |
RAID Controller | PERC H730 (internal HDDs) |
Power | Model NX3230 |
AC Power/Max Current | Redundant and non-redundant hot-plug 750W and 1100W PSU options |
Chassis | Model NX3230 |
Weight (Maximum) | 27.6kg (60.84lb) |
Height | 8.73 cm (3.44 in) |
Width | 44.40 cm (17.49 in) |
Depth | 68.40 cm (26.92 in) |
Availability | Hot-plug hard drives, hot-plug redundant power, hot-plug redundant cooling ECC memory |
Cluster Support | No |
Rack support | ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting |
Slots | Six PCIe 3.0 slots (four with x16 bandwidth and two with x8 bandwidth) |
